Working specifications

• Maximum punching capacity: 200 kN
• Maximum material thickness: 6.35 mm
• Punching accuracy: ± 0.1 mm

Hit rate (2 mm working stroke)

• 1 mm pitch — up to 920 HPM
• 25 mm pitch — up to 530 HPM
• Marking — up to 1750 SPM

Table

• Nominal sheet size: 1524 × 2500 mm
• Fully programmable work clamps (X, Y): 450 × 500 mm
• 3 floating, CNC-positionable clamps
• Combined axis traverse speed: up to 161 m/min
• Brush table: up to 150 kg

Power consumption

• Average consumption: approx. 6.7 kW
• Standby: approx. 0.9 kW
